Eurotorc ETW710/ETL711 Series Model Number Configurator

ETW710-T

ETL711-TX X X X

	Body
Cast Iron	1	GG25 Cast Iron (Enamel Coated)
Ductile Iron	2	GGG40
Carbon Steel	3	ASTM A216 WCB Carbon Steel (Enamel Coated)
Stainless Steel	4	ASTM A351 CF8M Stainless Steel

	Disc
Ductile Iron	1	GGG40 Ductile Iron (Black Rilsan Coated)
Ductile Iron	2	GGG40 Ductile Iron (Nickel Plated)
Ductile Iron	3	GGG40 Ductile Iron (Epoxy Coated)
Alu-Bronze	4	ASTM B148 Aluminium Bronze
Stainless Steel	5	ASTM A351 CF8 Stainless Steel
Stainless Steel	6	ASTM A351 CF8M Stainless Steel
Stainless Steel	7	ASTM A351 CF8M Stainless Steel (Polished)

	Seat
EPDM	1
NBR	2
FKM	3
SILICON	4
EPDM (WRAS)	5
NEOPRENE	6

	Pressure Rating
16 Bar	A
10 Bar	B
3 Bar	C
6 Bar	D

Material	Minimum Temperature °C	Maximum Temperature °C
EPDM SEAT	-18 °C	120 °C
NBR SEAT	-10 °C	80 °C
FKM SEAT	0 °C	160 °C
SILICON SEAT	-20 °C	140 °C
EPDM (WRAS) SEAT	-15 °C	120 °C
NEOPRENE	-15 °C	90 °C
RILSAN DISC COATING	-15 °C	80 °C
